Laser Glass Marking Machine

Picosecond Laser Marking Machine 800px

Laser Glass Marking Machine RM180

This high-end laser marking equipment, specifically developed for picosecond-level, high-precision, and fast processing, utilizes an ultrashort-pulse picosecond laser to achieve ultra-fine marking on a variety of materials. It is suitable for products requiring extremely precise marking and for processing brittle materials, especially for fine-detail marking on transparent and highly reflective materials. It offers excellent anti-counterfeiting properties and resists etching and oxidation. Its excellent performance in ultra-fine marking on medical devices, medical supplies, surgical tools, automotive precision parts, electronic components, mold engraving, chips, photovoltaic solar panels, and other high-end products has earned it a strong reputation.

Technical Table

Laser TypeInfrared Picosecond LaserUV Picosecond LaserGreen Picosecond Laser
Laser Power10W-100W3W-40W10W-40W
Wavelength1064nm355nm532nm
Beam Quality<1.3m2<1.3m2<1.3m2
Marking Area180mm*180mm (Customizable)180mm*180mm (Customizable)180mm*180mm (Customizable)
Marking Speed9000mm/s9000mm/s9000mm/s
Average Power Stability<3% (>24 hours)<3% (>24 hours)<3% (>24 hours)
Minimum Line Width0.01mm0.01mm0.01mm
Minimum Character Size0.2mm0.2mm0.2mm
Repeat Frequency50KHz-2MHz50KHz-2MHz50KHz-2MHz
Cooling MethodWater CoolingWater CoolingWater Cooling
